Product Overview

This Premium 2-Sided Mechanical Code Lock is designed to fit box sections measuring 30mm to 50mm. It features an aluminum housing and a robust stainless steel mechanism, ensuring long-lasting durability and security. The lock operates without the need for batteries or electricity, making it a practical solution for any gate requiring access control.

Key Features

• Mechanical code panel on both sides for convenience
• Ability to use different entrance and exit codes for added security
• Polyamide rain and dust cover to protect the locking mechanism
• Easy and quick setup or modification of access codes
• Adjustable polyamide roller bolt for smooth closing
• Extremely strong and user-friendly locking mechanism
• Automatic code reset after opening by pushing the handle
• Anti-code detection feature with an integrated security press plate
• Compatible with all standard locks

Dimensions & Specifications

Specification	Measurement
Suitable Box Section Width	30mm - 50mm
Deadbolt Throw	23mm
Weight	2.82 kg
Length	215.0mm
Width	110.0mm
Depth	31.0mm

Technical Specifications

• Material: Aluminum housing with stainless steel mechanism
• Installation: No batteries or electricity required
• Adjustability: 20mm continuous adjustability of the bolt

FAQ

1. How do I change the access code?

Changing the access code is simple and can be done quickly through the lock's settings.

2. Is the lock weatherproof?

Yes, the lock features a polyamide rain and dust cover that protects it from environmental elements.

3. Can this lock be used with any gate?

It is designed to fit gates with a box section width of 30mm to 50mm, making it versatile for various applications.
