Product Description
Heavy Duty Epoxy Line Marking Paint

Create clear, durable and professional floor markings with this heavy duty epoxy line marking paint. Designed for demanding industrial environments, this two-part coating provides excellent resistance to abrasion, chemicals and regular foot traffic.

Its thixotropic formulation offers a smooth, easy application before rapidly thickening to form sharp, permanent lines with minimal spreading. The high-gloss finish improves visibility and makes it ideal for separating pedestrian walkways, storage areas, loading zones and operational workspaces.

Suitable for factories, warehouses, workshops, production facilities and other high-traffic locations, this versatile epoxy coating can also provide robust protection in areas exposed to chemical spills, washing processes or frequent surface wear.

Key Features

• Heavy duty two-part epoxy resin coating
• Excellent chemical and abrasion resistance
• Creates clear, long-lasting floor markings
• High-gloss, professional coloured finish
• Solvent-free formulation
• Suitable for horizontal and vertical surfaces
• Easy to apply using a roller or brush
• Ideal for concrete, render, brickwork and blockwork
• Suitable for factories, warehouses and industrial floors
• Can be used in chemical spillage and containment areas

Typical Applications

This epoxy line marking paint is suitable for:

• Warehouse walkways and aisles
• Factory safety lines
• Pedestrian routes
• Loading and unloading zones
• Storage bay markings
• Workshop floors
• Industrial production areas
• Chemical spill zones
• Wash bays and wash boxes
• Process tanks, silos and containment bunds

Coverage

A 2.5kg unit provides coverage of up to:

• 50 metres of line at 100mm width and 0.5mm thickness
• 100 metres of line at 100mm width and 0.25mm thickness

Coverage may vary depending on the condition, texture and porosity of the surface.

Surface Preparation

Remove loose, damaged or flaking existing line markings before application. Repair any cracks, holes or defects using a suitable concrete repair compound and allow the repaired areas to dry fully.

The surface must be clean, dry and free from dust, laitance, grease, oil and other contaminants. Lightly abrade smooth or previously coated surfaces to improve adhesion. Remove all loose debris using a vacuum before applying the coating.

Application

The product is supplied as two components:

• Resin – Part A
• Activator – Part B

Mix both components thoroughly before application. Apply using a suitable epoxy roller sleeve, roller frame or brush.

Technical Information

• Finish: Coloured high gloss
• Composition: Epoxy resin with inert fillers
• Suitable substrates: Concrete, render, brickwork and blockwork
• Product type: Two-part epoxy coating
• Solvent content: Solvent free
• Pot life: Approximately 20 minutes
• Recoat or foot traffic time at 20°C: 8–12 hours
• Full drying time at 20°C: 12–24 hours
• Application tools: Epoxy roller or brush
