Product Overview

This Premium Motorised Hinge and Closer is designed for pedestrian gates, combining high-performance features with ease of installation. The integrated electronics ensure reliable operation and the product has been rigorously tested for durability and compliance.

Key Features

• Motorised gate closer with integrated electronics
• Torque: 100 Nm for powerful operation
• Compatible with post profiles from 60mm and gate profiles from 40mm
• Durable steel gear box for long-lasting performance
• Anodized aluminium cover for added protection
• Fast and easy installation with Quick-Fix technology
• ETL-tested for quality assurance
• Input main power supply: 110 AC to 240V AC
• Motor voltage: 24V DC
• External connection box with 3 inputs and 3 outputs (Max. 48W, 24V DC)
• Automated obstacle detection with reverse function for safety
• Brushless motor for a long lifespan and capacity for intensive use
• Reversible motor with backdrivability for easy manual operation
• Includes a 2m cable between the motor and connection module
• Compact and vandal-proof design for security
• Configuration available via app for user convenience
• Tested for up to 500,000 cycles for reliability
• Compliant with EN16005 standards for safety

Technical Specifications

Specification	Measurement
Torque	100 Nm
Input Power Supply	110 AC to 240V AC
Motor Voltage	24V DC
Connection Box	3 inputs and 3 outputs (Max. 48W, 24V DC)
Weight	0.0 kg
Length	398.0mm
Width	128.0mm
Depth	82.0mm

FAQ

• Q: How do I install the motorised hinge?
  A: The hinge features Quick-Fix technology for fast and easy installation on compatible gate profiles.
• Q: What safety features does this product include?
  A: It includes automated obstacle detection and a reverse function to enhance user safety.
• Q: How long is the warranty for the motorised hinge?
  A: The product is tested for up to 500,000 cycles, ensuring long-lasting reliability.
